Pulling force : 3630 kg (single line)
Motor : 12V DC Series-Wound
Cable : 8 mm x 30,5 m galvanized steel
Brake : automatic mechanical cone
Remote control : with 3.7m cable
Gear construction : 3 planetary gears
Transmission ratio : 162:1
Drum diameter / Length : 80mm / 229mm
Weight (transport kit) : 42 kg
Recommended battery : 650 minimum CCA for trolling
Finish : Satin black powder coated
The control device can be attached to the winch or remote mounted to allow more winch mounting options ( relocation kit required and sold separately )
More solid, more reliable and with a unique design
Attention! Winches are mounted on a dedicated bracket, specially made for each vehicle model! This is not included and must be ordered separately!
The minimum towing force for a winch is calculated by multiplying 1.5 by the maximum authorized mass of the vehicle in question!
CAUTION - when mounting winches on cars, there may be cases where it is necessary to relocate the control box for easier remote control access, a process which may incur additional costs during installation - using extension / relocation kits for control boxes.
