CAUTION - when mounting winches on machines, there may be instances where it is necessary to relocate the control box for easier remote control access, a process which may incur additional costs on installation - using extension / relocation kits for control boxes.
Pulling force: 5443 kg (single line)
Motor: 12V DC Series-Wound
Cable: 9.52 mm x 24.38 m galvanized steel
Brake: automatic mechanical cone
Remote control: with 3.7 m cable
Gear construction: 3 planetary gears
Transmission ratio: 216:1
Drum diameter / length: 80 mm / 229 mm
Weight (transport kit): 44 kg
Recommended battery: 650 minimum CCA for trolling
Finish: satin black powder coated
Control device can be attached to the winch or remote mounted to allow more winch mounting options (relocation kits required and sold separately)
Much stronger, much more reliable and with a unique design
Attention. Winches are mounted on a dedicated bracket, specially made for each vehicle model! This is not included and must be ordered separately!
The minimum towing force for a winch is calculated by multiplying the maximum authorized mass of the vehicle in question by 1.5!
